“Building a small frame means working through a pile of short joints, and the MIG-205DS fed smoothly from one connection to the next, leaving welds that looked solid enough as they were.”
MIG-205DS PRO
5 out of 5 stars4.8 (93 reviews)$367.20$459.00
or 4 payments of $91.80 with Klarna
A practical multi-process MIG welder, engineered for exceptional welding performance and versatile home use.
- User‑friendly controls and smart synergic settings make this welder an ideal choice for beginners
- Versatile performance across mild steel, stainless steel, and aluminum
- Dual voltage (110V/220V) for home garage or shop use
- Lightweight and portable for easy handling and storage
Info & Benefits
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit https://p65warnings.ca.gov.
Free standard shipping on orders over $150 within the contiguous US. Orders typically arrive in 3–5 business days. Expedited shipping options available at checkout.
Shipping policyIf you're not completely satisfied with your purchase, return it within 30 days for a full refund. No questions asked. Contact our support team to initiate a return.
Return policyCovered by a manufacturer warranty against defects in materials and workmanship.
Warranty termsGet the latest user manual and firmware for your machine.
The go‑to welder for beginners.
Smart Synergic MIG Control
- Synergic MIG
- Manual MIG
- Beginner Friendly
Designed with the beginner in mind, ensuring consistent results without guesswork. The synergic mode simplifies setup by automatically matching voltage and wire feed speed. Manual fine-tuning (±3V) is also available for greater control.
205AMax Output
Up to 5/8"Max Weld
Multi-Process Versatility
- MIG
- Flux-Cored
- Lift TIG
- Stick
Covers MIG, Flux-Cored, Lift TIG, and Stick welding to handle steel, stainless steel, and aluminum with a single machine. Simple to set up and reliable to operate, this unit is the best starting point for exploring various welding processes.
4-in-1Processes
60%Duty Cycle
Go-Anywhere Performance
- Dual Voltage
- Portable Design
- HD Digital Screen
Compatible with both 110V and 220V power sources, this unit offers maximum flexibility for home, workshop, or job-site use. Weighing only 22.7 lbs, the lightweight design makes it easy to transport and store wherever the work takes you.
120VHome
240VGarage
More Features
Tap each feature to see the details.
High-definition digital screen provides clear visibility and quick, accurate parameter adjustments.
Welds aluminum with 100% argon. Choose a graphene‑lined standard MIG torch with synergic control or a spool gun with manual control. Recommended wires: ER4043 and ER5356.
Monitors wire feed speed and current in real time for better process visibility and control.
Provides total control over wire feed speed and voltage for tailored welding habits.
Built for Every Job
“Access was the hardest part of these angled tube intersections. The 205DS stayed manageable in the tight spots, so I could work around each junction without the arc feeling erratic.”
“A few bends and short welds finished the bracket. The MIG-205DS needed little setup and stayed manageable in the close corners.”
“Spec sheets are fine, but I judge a welder by the bead. The MIG-205DS ran evenly around this corner joint, and the finished seam was one I would gladly show.”
Materials × Thickness.
Recommended process
Stick
TIG
MIGFlux-cored
StickTIGMIGFlux-cored5 × US $11 coin=2mm5 coins=10mm
Minimum20 GA0.9 mm
Maximum19/32"15 mm
Specifications
Power & Output
- Input Voltage
- 110V, 220V ±10% 50/60Hz
- Processes
- MIG, Flux-Cored, Lift TIG, Stick
- Output Current Range
- MIG: 30-160A @ 110V; 30-205A @ 220V TIG: 15-140A @ 110V; 15-205A @ 220V Stick: 20-140A @ 110V; 20-205A @ 220V
- Duty Cycle
- MIG: 60% @ 205A
- Detailed Duty Cycle
- MIG (110V): 60% @ 160A; 100% @ 123A MIG (220V): 60% @ 205A; 100% @ 158A TIG (110V): 60% @ 140A; 100% @ 108A TIG (220V): 60% @ 205A; 100% @ 158A Stick (110V): 60% @ 140A; 100% @ 112A Stick (220V): 60% @ 205A; 100% @ 139A
Material & Capability
- Material Compatibility
- MIG: Steel, Stainless Steel, Aluminum TIG: Steel, Stainless Steel Stick: Steel
- Recommended Thickness
- MIG: ≤ 3/16" (5 mm) @ 110V; ≤ 1/2" (13 mm) @ 220V TIG: ≤ 1/8" (3 mm) @ 110V; ≤ 5/16" (8 mm) @ 220V Stick: ≤ 5/16" (8 mm) @ 110V; ≤ 19/32" (15 mm) @ 220V
MIG
- Synergic Function
- Supported
- Spool Gun Compatibility
- Supported
- MIG Wire Type
- ER70S-6 / E71T / ER308L / ER4043 / ER5356
- Wire Diameter
- .023" (0.6 mm) / .030" (0.8 mm) / .035" (0.9 mm) / .045" (1.1 mm)
- MIG Torch Type
- YW-L150-10E (European connector)
- Gas Requirements
- CO2 100%, Mix Gas, Argon 100%
- Wire Feed Mechanism
- 2-Roll, 4-Roll
- Consumables Compatibility
- Magnum 100L
TIG
- TIG Ignition Type
- Lift Start
- Foot Pedal Compatibility
- Not supported
- Tungsten Type
- WT20, WC20, WL20, WL15
- Tungsten Diameter
- ≤ 3/32" (2.4 mm)
- TIG Torch Type
- WP-17V-35 (Optional. Sold separately.)
- TIG Filler Rod Material
- ER70S-6, ER308L
- TIG Filler Rod Diameter
- ≤ 3/32" (2.4 mm)
- Gas Requirements
- 100% Argon
- Consumables Compatibility
- WP-17 / WP-18 / WP-26
Stick
- Stick Electrode Type
- E6013 / E7018
- Stick Electrode Diameter
- ≤ 5/32" (4.0 mm)
Plasma Cutting
- CNC Capability
- Not supported
Physical & Safety
- Display
- LED
- Fan Control
- Continuous Fan Mode
- App Control
- Not supported
- Weight
- 22.7 lbs
- Dimensions
- 16.93" × 8.27" × 14.17"
- Protection Features
- Overheat Overcurrent Undervoltage
General
- Input Current
- 50A @ 110V; 40A @ 220V
- Open Circuit Voltage (OCV)
- MIG/TIG/Stick: 65V
- Generator Compatibility
- Generator not recommended. If necessary, use at least a 10 kW (15 HP), 120/240V generator with AVR.
- Cable Length
- Ground: 10 ft (3 m) MIG Gun: 10 ft (3 m)
- Power Cord Length
- 6.5 ft (2 m)
- Certification
- CE, ETL, UL
- Warranty
- 2 Years
All the essentials. And then some.
How it compares.
MIG-205DS PRO
Synergic multiprocess MIG that handles aluminum with a spool gun.
From $367.20$459.00
Currently viewing
- 205A synergic MIG
- Key Feature
- LED
- Display
- Steel / Stainless / Aluminum
- Material Compatibility
- ≤ 19/32" (15 mm) @ 220V
- Recommended Thickness
- 205A
- Max Output
- MIG / Flux / TIG / Stick
- Processes
- 110V / 220V
- Input Voltage
DP200
Dual-pulse MIG that welds aluminum like a pro.
From $579.99$699.00
- Dual Pulse MIG
- Key Feature
- 7" LCD
- Display
- Steel / Stainless / Aluminum
- Material Compatibility
- ≤ 3/8" (10 mm) @ 240V
- Recommended Thickness
- 200A
- Max Output
- MIG / Flux / TIG / Stick
- Processes
- 120V / 240V
- Input Voltage
FLUX-135PRO
Gasless flux-core 3-in-1 that runs on any 110V outlet.
From $159.00
- Synergic flux-cored
- Key Feature
- LED
- Display
- Steel / Stainless
- Material Compatibility
- ≤ 3/16" (5 mm) @ 110V
- Recommended Thickness
- 135A
- Max Output
- Flux / TIG / Stick
- Processes
- 110V
- Input Voltage
Before you ask.
The MIG-205DS-PRO supports MIG, FLUX, Lift TIG, Stick, and spool gun MIG welding.
Yes. The MIG-205DS-PRO supports both 110V and 220V input.
At 220V, output is 30-205A in MIG, 20-205A in Stick, and 15-205A in TIG. At 110V, output is 30-160A in MIG, 20-140A in Stick, and 15-140A in TIG.
Yes. The MIG-205DS-PRO supports aluminum welding with spool gun MIG setup.
Yes. Manual MIG mode lets you customize wire feed speed and voltage according to your welding preference.
The MIG-205DS-PRO is designed for steel, stainless steel, aluminum, and flux-cored wire applications.
What customers are saying.
Rating snapshot
5 stars
75
4 stars
18
3 stars
0
2 stars
0
1 star
0
Overall rating4.85 out of 5 stars93 reviews
Review this product
Share your experience with other welders.
Mel Friedman15 hours ago
5 out of 5 starsThe best
I took up welding when I retired fifteen years ago. Mostly self -taught. Bless you tube. I've been through a bunch of different welders. When I got to the Yes Welder Mig 205 DS Pro I stopped. Too many positives to list. The one I love the most, is I check the thickness, I set the speed and the welder does the rest.
David Placker2 weeks ago
5 out of 5 starsI am pleased with this welder
I am pleased with this welder. It has been meeting my expectations and I hope it continues to do so. I am only in the first stages of the project I am using it primarly for. I have done some plug welding and welding in a patch on some 20 gauge automotive steel from the late 1960's. If you would like I can go further into detail once this first section is completed. I will have by then have logged much more time on this machine.
fabian caballero2 months ago
5 out of 5 starsTried this machine with everything Stick, Mig,
Tried this machine with everything Stick, Mig, Tig, spool gun such an awesome incredible machine done stainles, aluminum, carbon steel welded on hevy equipment like coil tubing units and hasn't failed me
Brian Schuele2 months ago
4 out of 5 starsAs a beginner, it’s very easy to use, setup is easy, setting
As a beginner, it’s very easy to use, setup is easy, setting parameters is a cinch..
Natalie Whitcomb3 months ago
5 out of 5 starsMIG-205DS-Pro Multi-Process MIG Aluminum Welder
MIG-205DS-Pro Multi-Process MIG Aluminum Welder
Nathan Worszylo3 months ago
5 out of 5 starsMIG-205DS-Pro Multi-Process MIG Aluminum Welder
MIG-205DS-Pro Multi-Process MIG Aluminum Welder
Jhenesith Vanegas7 months ago
5 out of 5 starsMIG-205DS-Pro Multi-Process MIG Aluminum Welder
MIG-205DS-Pro Multi-Process MIG Aluminum Welder
Kurtz8 months ago
5 out of 5 stars2nd Mig205ds
I had the same model a few years ago (the blue one). It stopped producing amps and I thought, what a waste of money. I bought a cheap welder to replace it and it wouldn't hold a steady arc, so I broke down and bought another yeswelder 205ds, the newer, upgrade model. I am impressed. It's twice the welder of the cheap one, and much nicer than the original 205ds. I'm using straight CO2 and it provides very nice even welds. I think this one will last a long time and I have spare parts from the other one. I'm satisfied.
Wilberto Quinones8 months ago
5 out of 5 starsGreat deal
Im very happy with my welder I didn't even used yet, but like
Customer8 months ago
5 out of 5 starsSo far so good!
Have only used the flux core process so far and my expectations have been met thoroughly! As soon as I secure some gas bottles I'll try TIG, gas MIG and will add spool gun option. The Yeswelder flux core wire is EXCELLENT!
Showing 1–10 of 93 reviews
