Multi-process MIG Welder
YWM-160 Multi-process Welder
MIG/Lift TIG/ Stick in 1
3 in 1 Welder
YesWelder MIG welder
Color Screen MIG Welder

YWM-160 Flexible Manual MIG Controlled Multi-process MIG Welder

YWM-160

Regular price225.99
/
Shipping calculated at checkout.

  • Free Continental US Shipping Over $150
  • 3 Year Warranty
  • In stock, ready to ship
  • Inventory on the way

 This welder is suitable for stainless steel and mild steel, making it widely applicable in industrial and home settings.

Smart MIG Set:

The smart set makes welding easy with pre-set MIG machine settings. And anyone who uses the welder could get rid of working with variable amperage, voltage, and wire feed speed. Simply choose the wire thickness and gas want to run, then set the amperage as the recommended one with the material thickness in the welding chart. The smart set system will have the rest of the setting dialed in to give an ideal arc condition. It also allows fine-tuning the auto-adjusted voltage to ±5V to personalize the setting for optimal results.

Manual MIG Set:

Experienced and professional welders could set the wire feed speed and voltage however they would like to set, no limitation for wire thickness and the running gas.

 Color Led Screen:

 It comes with intuitive and an easy-to-use control panel. Color LED screen visualizes the welding process and parameters shield gas, 2T/4T torch trigger preference and voltage, wire feed speed, and wire diameter.

Wide Application:

This welder is suitable for stainless steel, and mild steel, widely used in industrial and home settings.

For MIG welding

Capable welding with 2-lbs and 10-lbs welding wire (4" or 8" wire diameter: D100/D200) for carbon steel and stainless steel workpieces.

Using .030”/.035" ER70S-6 mild welding wire for welding carbon steel workpiece with 100% CO2, 75% Argon 25% CO2

Using .030”/.035”  E71-GS flux core wire welding carbon steel workpiece without gas.

Using .030”/.035" ER308L mild welding wire for welding carbon steel workpiece with 98% Argon 2% CO2.

For Lift TIG welding

With an additional lift TIG torch WP-17V-10, it could weld carbon steel and carbon steel workpiece under a suitable TIG filling rod with 100% Argon.

For Stick welding

It could weld carbon steel workpieces with E7018, E6013, and E6011 electrodes.

Most items are usually shipped within 3-5 working days. Your delivery confirmation email will contain your tracking number and order details.

Should you have any questions, our team is also on hand 7 days a week and can be reached at support@yeswelder.com.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

YWM-160

110V / 220V Dual Voltage / Gas MIG/Gasless MIG/Lift TIG/Stick 4 in 1 / Synergic & Manual MIG Setting /Ideal for 7018/6011 Electrode.

FEATURES

  • 4 Functions in 1: Gas MIG /Gasless MIG / Lift TIG / Stick (TIG torch not included)
  • Capable of welding carbon steel, stainless steel.
  • Synergic Controlled MIG function, suit for new welders and inexperienced welders.
  • Suitable for 0.8 & 0.9mm (.030“ & .035").
  • Apply to D100/D200 rolls (≤10lbs) of MIG wire.
  • Dual Voltage: 110V and 220V, meet household DIY and industrial usage.
  • Suitable for 7018/6011 electrode.
  • Flexible and non-limited MIG settings make welding easy by allowing adjustment of voltage and wire feeding speed

Quick-Selection Design

Allows for easy switching between different welding modes to meet various welding requirements (Gas/Gasless MIG, Stick, or Lift TIG).

Synergic/Manual Controlled MIG

Suits the needs of hobbyists and professional welders.

Dual Voltage

Capable to run directly on 110V (±10%) 50/60 Hz power or on 220V (±10%) 50/60 Hz with the use of a power adapter.

Smart
MIG Setting

The smart set makes welding easy with pre-set MIG machine settings. Anyone who uses the welder simply chooses the wire thickness and the desired gas, then sets the amperage to match the recommended value for the material thickness indicated in the welding chart. The smart set system will automatically adjust the rest of the settings to achieve an ideal arc condition.

It also allows for fine-tuning the auto-adjusted voltage to ±5V to personalize the settings for optimal results.

Manual
MIG Setting

Experienced and professional welders can set the wire feed speed and voltage as they prefer, with no limitations on wire thickness or the choice of shielding gas.

Colored
Led Screen

It comes with an intuitive and easy-to-use control panel.The color LED screen visualizes the welding process and displays parameters such as shield gas, 2T/4T torch trigger preference, voltage, wire feed speed, and wire diameter.

Wide
Application

This welder is suitable for stainless steel and mild steel, and it is widely used in industrial and home settings.

  • Capable welding with 2-lbs and 10-lbs welding wire (4" or 8" wire diameter: D100/D200) for carbon steel and stainless steel workpieceswith or without shield gas in MIG welding mode. Shield gas: 100% CO2, 75% Argon 25% CO2, and 98% Argon 2% CO2.
  • With an additional lift TIG torch WP-17V-10, it could weld carbon steel and carbon steel workpiece under suitable TIG filling rod with 100% Argon in Lift TIG welding mode.
  • It is capable of welding carbon steel workpieces with E7018, E6013, and E6011 electrodes in stick welding mode.
Wire Recommendation

Compatible with 2-lbs and 10-lbs welding wire (4" or 8" wire diameter: D100/D200).

Suitable for several welding requirements.

.030”/.035" ER70S-6 mild steel MIG welding wire and E71-GS flux core wire for welding carbon steel workpiece

.030”/.035" ER308L stainless steel wire for welding stainless steel workpiece

Specifications
  • Product weight: 33.9lb
  • Product Dimensions:21.7"*13.5"*10.8"
  • Supply Voltage: 110V/220V 50/60 Hz
  • Input Current: 50A@110V, 30A@220V
  • Output Current:
  • @220V: 40-160A (MIG) 20-160A (Stick) 20-160A (TIG)
  • @110V: 40-120A (MIG) 20-120A (Stick) 20-120A (TIG)
  • Duty Cycle (MIG): @110V, 60%@120A, 100%@93A @220V, 60%@160A, 100%@124A
  • Wire Spool: 2LB/10LB
  • Welding Material: Carbon Steel/Stainless Steel
  • Protection Class: IP21S
