Non-HF Plasma Cutter CUT-65DS | Non-Touch Pilot Arc Cutting Machine

Regular price
559.99
Sale price
559.99
Regular price
650.00
Sold out
Unit price
per
Non-HF Cuttting Machine / Non-Touch Pilot Arc/ Dual Voltage 110/220V
  • DURABILITY
  • EASY SETUP
  • COMPATIBILITY

Download Product Manual
Non-HF Plasma Cutter CUT-65DS | Non-Touch Pilot Arc Cutting Machine
Non-HF Plasma Cutter CUT-65DS | Non-Touch Pilot Arc Cutting Machine
-
+
Section

CUT-65DS

The YesWelder CUT-65DS cutter adpot “blow-back” start-a non-high frequency start. An excellent choice for home DIY jobs and light duty small business projects, and professionals.

FEATURES
  • Non-Touch Pilot Arc
  • Dual Voltage 110/220V
  • Powerful and Clean cut up to 1/2"
  • IGBT Inverter  Technology

Digital Display

Adopts international leading MCU intelligent digital control technology

 Clean Cut

Max Rated Clean Cut Thickness: 5/8".Max Severance Thickness: 63/64"

No HF Start

“Blow-back” start--no HF interference

Non-touch Pilot Arc

Cut without touching the tip to the metal. Better cutting quality and longer consumable life

FUNCTION

Non-HF Start

  • The “blow-back” start comes without interference and is safe and ideal for general use, friendly to the surrounding electrical machine and human health
  • Cutting Material:Stainless steel, Alloy steel, Mild steel, Copper, Cast Iron and Chrome.

Non-touch Pilot Arc

  • The pilot arc torch efficiently cuts through rough, painted, and rusty surfaces, while producing minimal slag.
  • Pilot arc technology allows you to cut without touching the tip of the metal, for better quality and longer consumable life.

Powerful Clean Cut

  • Ideal Clean Cut: 5/16" @110V, 5/8"@220V
  • Maximum Severance Cut: 5/8" @110V, 63/64"@220V

Digital Control

  • Plasma cutter CUT-65DS adopts international leading MCU intelligent digital control technology, and all its major parts are performed through software.
  • 1. 2/4T Function
  • 2. Mode Selection: Gas Checking/ Cutting
  • 3. Gas Connector
  • 4. Pilot ARC
  • 5. Torch Control Switch
  • 6. Earth Clamp Connector
  • 7. Value Control Knob
  • 8. Output Current Display
  • 9. Voltage Display

Air Filter Regulator

  • The air regulator is mounted at the back machine and used to adjust the outlet pressure.
  • Pay attention to the airflow direction, and follow the arrow on the filter. Wrong airflow direction will not let the air in and make the cutting machine not work properly.
  • Pull up the knob of pressure gauge and rotate clockwise, pressure will rise steadily; pressure will down if rotate by counterclockwise.
  • When reaching to required pressure and lock down the knob in case of leaking.

Note:   External Air Compressor, need to purchase separately

Product Details

HEAL A CHILD'S SMILE

1

Portability

IGBT inverter, smaller size and lighter weight, and higher reliability allows you to take to wherever the job is needed.

CLEAN WATER FOR LIFE

2

Digital Control

Able to adjust the pilot arc time, pilot arc current, cutting current and post slow time.

STOP THE HUNGER

3

Dual Voltage

Capable to run directly on 110 V (±10%) 50/60 Hz power or on 220 V (±10%) 50/60 Hz with the use of a power adapter.

Specification

PRODUCT DETAIL

Product weight: 21.8lb

Product Dimensions: 19.2" *15"* 11.45"

Input Voltage: 110V/220V 50/60 Hz

Input Current: recommend 63A breaker

Cutting Recommendation:
Output current 25A, @110V  50.8PSI
output current 45A, @220V 62-72PSI

Duty Cycle :100%@45A, 60%@65A

Air Compressor Requirement: 5-7CFM @72PSI

Welding Material: stainless steel, alloy steel, mild steel, copper, and aluminum, and other color metal materials

Protection Class: IP21S

Package includes

  • 13' S45 Cutting Torch
  • 10' Earth clamp & cable
  • Gas hose
  • Air Flow Gauge
  • Air Compressor Filter
  • 110V/220V Adapter
  • Electrode Installation Wrench
