CUT-55DS Pro
The YesWelder CUT-55DS Pro cutter adpot “blow-back” start-a non-high frequency start. An excellent choice for home DIY jobs and light duty small business projects, and professionals.
FEATURES
- Non-Touch Pilot Arc.
- Non-HF Interfere.
- Dual Voltage 110/220V.
- Powerful and Clean cut up to 25/64".
- IGBT Inverter Technology.


Portability
IGBT inverter, smaller size and lighter weight, and higher reliability allows you to take to wherever the job is needed.

Digital Control
Able to adjust the pilot arc time, pilot arc current, cutting current and post slow time.

DUAL VOLTAGE
Capable to run directly on 220 V (±10%) 50/60 Hz power or on 110 V (±10%) 50/60 Hz with the use of a power adapter.

The “blow-back” start comes without interference and is safe and ideal for general use, friendly to the surrounding electrical machine and human health.
Cutting Material: Stainless steel, Alloy steel, Mild steel, Copper, Cast Iron and Chrome.
The pilot arc torch efficiently cuts through rough, painted, and rusty surfaces, while producing minimal slag.
Pilot arc technology allows you to cut without touching the tip of the metal, for better quality and longer consumable life.


Ideal Clean Cut:
13/64” @110V, 25/64”@220V
Maximum Severance Cut:
5/16”~ 25/64”@110V, 5/8”~25/32”@220V
CUT-55DS Pro adopts international leading MCU intelligent digital control technology, and all its major parts are performed through software.
- Adjustment Knob
- Torch Connector
- Pilot Arc Connector
- Torch Control Switch
- Earth Clamp Connector
- Power Switch
- Power Cable
- Air Compressor Filter
- Cooling Fan


- Product weight: 13.38lb
- Product Dimensions: 15.2" *5.9"* 12"
- Input Voltage: 110V/220V 50/60 Hz
- Input Current: recommend 63A breaker
- Cutting Current: 20A@110V, 20-40A@220V
- Duty Cycle: 60% @ 25A,100% 20A @110V,60% @ 55A,100% 42A @ 220V
- Air Compressor Requirement: 4-7CFM @58-116PSI
- Welding Material: stainless steel, alloy steel, mild steel, copper, and aluminum, and other color metal materials.
- Protection Class: IP21S
