The MP200 is a versatile and powerful 5-in-1 welding machine specially designed for home DIY or maintenance projects. It can be used to weld MIG (GMAW), Stick (SMAW), Gasless (FCAW), and TIG (GTAW). YesWelder MP200 also allows you to cut at the same time. Suitable for both home DIY and industrial projects.
- Synergic Controlled on MIG function, very easy and simple operation.
- Gas MIG/Gasless MIG/Lift TIG/Stick/CUT 5 in 1.
- Can take up to 0.9mm(.035") MIG solid wire(Gas MIG) and 0.9mm(.035") MIG FLux wire(Gasless MIG).
- Apply to D100/D200 rolls (<10lbs) of MIG wire.
- Ideal for 7018/6011/6010 electrode.
- Smart Memory & System Reset.
4.3” high-pixel LCD control screen that quickly and easily walks the user through setup,smoothly flow through the on-screen menu system and choose the setting.
Digital control to choose welding mode, material, welding wires, tungsten rods, electrode and workpiece thickness.
Color LCD display easy to read and set amperage and wire speed for repeatable welds every time.
Full Synergic Option: with automatic change of the voltage & wire feeding speed by choosing different thicknesses or amperage.
The wire feed speed will be well fit with the amperage with micro-adjust voltage.
“Out Range” warning: if the amperage/ wire speed is not relative to the MIG setting, the thickness will automatically change to the related ones.
Burn Back Control: Allowing burn back time adjusting during the weld, suitable to different welding requirement.
Equipped with a TIG torch and easy to initiate arc ignition.
Supplying stable controllable consistent arc, suitable for small or intricate welding projects.
Allowing clean and quiet, virtually smoke-free welding with 100% Argon.
Exceptional DC stick welding provides excellent fusion and bead characteristics.
Built-in hot start and arc force allows capability of welding with E7018 electrode & E6011 , E6010 cellulose electrodes.
Electrode up to 1/8" (3.2mm) @110V, 13/16" (5mm) @220V.
Apply to 13/16" (5mm) @110V, 9/32"(7)@220V.
Brief and clear connection icon could be a good reminder for different electrode requirements.
The preflow is a purge feature to insure there is airflow at the tip to become a charged plasma stream and benefit for blowing clean cuts.
Postflow is primarily for cooling.the longer the cut at high amp on thick metal, the more post flow need to dissipate the heat.
Recommend air pressure: 58-72 PSI.
Max Severance Thickness: 15/32"(12mm)@220V@40A, 5/16"(8mm)@110V@30A.
Max Clean Cut Thickness: 25/64"(10mm)@220V@40A, 15/64"(6mm)@110V@30A.
The smart Memory function allows you to store the voltage and current settings that match your style under memory numbers.
The memory number can be recalled to reveal and use the weld parameters stored, and weld parameters can be further adjusted and stored as required.
Up to 10 memory options for each type of welding can be memorised and stored for recall.
Adopts both imperial and metric systems of measurement.
When the machine is perfoming uncharacteristically, all the welding parameter is able to be restored to the factory setting.
It will reset theprimary log data, process logdata, and error log data.
Contrast settings, motor calibration settings, Spoolmate calibration settings, burn-In information, and software information will all beretained.
It could be used to prepare a device for donation or other transfers of ownership by removing personal data and configurations associated with the previous owner.
Product weight: 41lb
Product Dimensions: 20.08"*11.02"*6.10"
Supply Voltage: 110V/220V 50/60 Hz
Input Current: 45A@110V, 30A@220v
Air Compressor Recommendation:9-12CFM@ 78PSI.
Pre/Post Flow Time (CUT): 10s
Can apply to 2 and 10 pound rolls of wire, .030"/0.35".
Welding Material: Carbon Steel, Stainless Steel.
Protection Class: IP21S
