Types of Welding Joints Explained

Creating a sound weld is more than just running a high-quality bead across the joint. It is a long process that requires good weld preparation and post-weld treatment.

Welders must be aware of the mechanical and metallurgical properties of each metal and understand the various techniques and practices used in the industry. One crucial part of creating a solid bond between two pieces of metal is making a proper joint design.

Making the appropriate design requires a proper understanding of the welding joints. That's why we'll explain 5 major types of welding joints, their variations, and their applications.

5 Major Types Of Welding Joints Explained

Welding joint design, or type of welding joint, refers to the way pieces of metal are put together or aligned for welding. You can align the two pieces parallel, perpendicular, or by overlapping the edges. The way you put them together can have a different impact on the properties of the weld.

There are five major types of welding joints:

Understanding how major types of welding joints affect the properties of the weld can make or break your next welding project. That's why we'll explain the properties, types, and applications of each type of welding joint.

Butt Joint Welding

Butt joints are one of the most common welding joint designs widely used in metal fabrication, pipe welding, or construction. You are likely to use butt joint welding as a beginner or for hobby welding.

In butt joint weld design, the two pieces of metal are laid parallel with their edges touching. Welders place the pieces in the same plane, and you put your welds where two edges meet.

Source: https://www.twi-global.com/technical-knowledge/faqs/what-is-a-butt-weld

What makes butt joint welding so popular is the fact you need little to no edge preparation. You can leave the small gap and create a root opening, bevel the edges, or join them without any gap. Based on the amount of preparation and appearance of edges, we are seeing various types of butt joints.

Types of Butt Joints

Depending on the type and thickness of the metal, the applications of welded parts, and more, welders modify the edges of the butt joints, creating one out of various types. Welders prepare and shape the faying surface, or the surface that melts during the welding, creating one of the most common types of butt joints such as:

• Square butt joints
• Single or double-beveled butt joints
• Root opening butt joints

Source: https://constructionmanuals.tpub.com/14250/css/Butt-Joints-51.htm

Welders use a square butt joint where no edge preparation is required. That's typically the case when welding thin metal pieces or pipes. The weld can adequately penetrate the thin pieces and produce sound and solid welds.

However, once the thickness of the metal increases, welders bevel the pieces and use multi-pass welding to fill the joint and create strong welds. Weld specifications can state the angle and shape of the bevel and the size of the root opening or the gap between two pieces.

Based on the shape and number of the bevels in the preparation, butt joints can be:

• Single bevel joints
• Double bevel joints
• Single J butt weld
• Double J butt weld
• Single V butt weld joint
• Double V butt weld joint
• Single U butt joint
• Double U grooves

Butt Joint Preparation Method
Source: https://www.facebook.com/engineeringinsider

Shaping the bevels in the form of J, V, or U can increase the amount of deposited weld metal and, therefore, the strength of the weld. Although the wider joints can be stronger, they require more welding and time spent welding.

In critical applications, a welding engineer can specify the exact size, shape, and angle of the bevel. Otherwise, you will have to judge the required parameters based on your experience and adapt to the specific size of the pieces.

Applications Of Butt Joint Welding

Welders widely use butt joints in pipeline welding, shipbuilding, structural steel welding, pressure vessels, large tanks, and general metal fabrication.

For example, welders often use butt welds in pipeline welding, especially in the oil and gas industry. They are ideal for joining sections of pipes to ensure a smooth flow of liquids or gases. In shipbuilding, welders use butt joints to join large steel plates together to form the hulls and other structural components of ships.

The construction industry uses butt joints to join steel beams and columns, creating strong, continuous structures capable of bearing significant loads. In the automotive sector, butt welds join various components of the vehicle's frame, body panels, and exhaust systems.

Pros and Cons of Butt Joints

Pros of butt joints:

• Simple and easy to prepare: The pieces need to be aligned edge-to-edge, making the setup process straightforward.

Source: https://www.youtube.com/watch?v=9-SsPVLj7rM&t=418s

• Robust joint design: When appropriately welded, butt joints can provide a strong and durable connection.
• Minimal material waste: Butt joints do not require additional material like filler metal beyond what is necessary for the weld itself
• Suitable for thick and thin Materials: Butt joints are versatile and can be used with both thick and thin materials.
• Uniform stress distribution: The joint allows for a relatively uniform distribution of stress across the welded area.
• Aesthetic finish: Butt joints often result in a clean, flush finish when ground smooth.

Cons of butt joints:

• Potential for Distortion: Welding heat can cause distortion, especially in thinner materials.
• Risk of Weld Defects: Butt joints can be prone to defects such as porosity, cracks, and lack of fusion if not welded properly.
• Alignment Challenges: Proper alignment of the two pieces is crucial for a successful weld
• Requirement for Edge Preparation: Depending on the material thickness, the edges of the pieces might need to be beveled or prepared to ensure complete penetration of the weld.

Tee Joint Welding

Tee joints, or fillet welds, are also one of the most commonly used joint designs. Welders use a fillet weld in many fabrication applications, such as welding structural steel, tubing, and equipment. In this weld joint design, the two pieces of metal are perpendicular and meet at approximately 90 degrees. This alignment forms a letter "T," hence the name Tee weld joint.



Welders can weld on one side of the Tee joint, which will be subject to any stress, or weld on both sides. Welding on both sides of the joint takes more time, but it produces maximum strength, which is required when the joint is subjected to stress from both sides.

What makes this joint configuration so popular among welders, especially new welders, is the fact it requires little to no edge preparation. Unlike butt welds, welders rarely shape or bevel the edges, so it is a pretty straightforward joint design. In addition, you can weld Tee joints in flat, horizontal, vertical, or overhead positions, which can be pretty challenging with butt welds.

Types Of Tee Joints

While there is no edge preparation like with butt welds, there are variations of Tee joints. The most common types of Tee joints include:

• Plug weld
• Slot weld
• Bevel-groove weld
• Fillet weld
• J-groove weld
• Melt-through weld
• Flare-bevel-groove weld

Source: https://www.mechdaily.com/types-of-welding-joints/

Although edges are rarely beveled in Tee joints, you can use them when welding thick metals. It can also serve as a support if the joint cannot withstand the load, even though you weld both sides of the joint.

Applications of Tee Joints

Tee joints are widely used in general fabrication, structural framework, pipe fitting, shipbuilding, or furniture making.

For example, welders use Tee joints to connect horizontal beams to vertical columns in the construction of structural frameworks. Welders use Tee joints to connect pipes at a perpendicular angle in plumbing systems.

In addition, you can use Tee joints in metal reinforcement to provide additional support beams or braces. Tee joints are used in the automotive industry to assemble various components of vehicle frames, chassis, and other structural parts.

Tee Joints Stick Welding Process
Photo by @weldd1 (TikTok)

Pros and Cons Of Tee Joints In Welding

Pros of Tee Joints in Welding:

• Strong Structural Support: Tee joints provide excellent structural support for pieces welded at the right angle.
• Versatile applications: Widely used in construction, automotive, shipbuilding industries, and various other industries.
• Good load distribution: Tee joints can effectively distribute loads across the welded area.
• Easy preparation: Aligning materials is straightforward, making it easy to set up for welding.

Cons of Tee Joints in Welding:

• Prone to stress concentration and cracking: The joint can be prone to stress concentration at the weld root, potentially leading to failure under high loads.
• Risk of distortion: Welding can cause distortion, particularly in thinner materials.
• Welding thick pieces can be challenging: Achieving full penetration can be difficult, especially in thicker materials requiring more passes.

Lap Joint Welding

Lap joints are a modified variant of butt joints. The metal pieces are also on the same plane, but the edges of the pieces overlap, ergo the name lap joint. The welders place welds where the two pieces intersect, and you can choose to weld one or both sides if you need additional strength of the weldment.

Due to their nature, welders use lap joints when welding plates or sheet metal. This weld joint configuration can help you reduce the amperage and use a faster travel speed, which is crucial in avoiding distortion and burn-through in sheet metal welding.

In the lap joint weld preparation, you should make sure there are no gaps between the two workpieces. As a variant of the butt joint, lap joints can provide more strength in higher-stressed areas. However, lap joint welding does not result in a flush contour.

Source: https://hitopindustrial.com/types-of-welding-joints/

Applications Of Lap Joint

Lap joints are widely used in various industries that require sheet metal welding. These industries most commonly include sheet metal fabrication, automotive welding, the electrical and aerospace industry, and container-making.

The most notable application of lap joints is in sheet metal fabrication. A typical example is assembling car body panels, roofs, and doors in the automotive industry. You can use it to weld thin materials, such as aluminum and titanium sheets, in the construction of aircraft skin, fuselage panels, and wing structures.

Pros and Cons Of Lap Joints In Welding

Pros of Lap Joints in Welding:

• Simplicity: Easy to prepare and align for most welding projects.
• Suitable for thin materials: Effective for joining thin sheets and plates.
• Strong shear strength: Laps provide good shear strength and are suitable for applications where shear loads are predominant.
• Versatile joint design: Widely used in automotive, aerospace, and metal fabrication industries.

Cons of Lap Joints in Welding:

• Limited load bearing: Not ideal for applications that require high tensile strength.
• Potential for Corrosion: The overlapping area can trap moisture, increasing the risk of corrosion over time.
• Overlapping material: The overlap creates a thicker joint, which can lead to material waste and increased weight.

Corner Joint Welding

Corner joints are an alternative to tee joints, where two pieces meet perpendicularly. This time, they resemble the corner of a box or frame. In Tee joints, one piece intersects the middle of the base piece. As the name states, two pieces meet in a corner, forming the letter "L."

Like Tee joints, corner joints require little to no weld preparation. You align and clamp the pieces in the corner, which is highly useful when creating square frames in weld tables, furniture, or other weldments.

While edge preparation is relatively simple, you will need a proper fit-up with corner joints. If welds require a 90-degree angle, you should consider possible distortion during welding. Distortion means the angle can change after welding, and you can prevent it by creating a jig or fixture that holds the parts in place.

Types Of Corner Joints

Depending on the part fit-up, there are three types of corner joints:

• Open corner joints
• Closed corner joints
• Half-open corner joints

In open corner joints, the two metal edges touch. This creates a V shape and, depending on the material thickness, often requires more weld metal.

A closed joints forms once one edge of the metal touches the face of the other metal. This configuration typically yields much higher mechanical strength, but it can be more complex than open corner joint.

Half-open corner joints form when the edge touches the face of other metal, but it doesn't completely cover it. To provide higher strength, you weld two sides of the corner joint to fill the missing gap and the corner of the weldment.

You can create corner joints using one out of many styles, such as:

• U-groove
• J-groove
• V-groove
• Spot
• Edge and fillet
• Corner-flange
• Bevel-groove
• Flare-V-groove
• Square-groove or butt

Applications Of Corner Joints

Key applications of corner joints in welding include metal frames, furniture making, sheet metal welding, fabrication, and custom metalwork welding.

Welders use corner joints, most notably, to construct metal frames and enclosures, such as boxes, cabinets, and containers. When creating metal furniture, corner joints connect the legs, arms, and frames of items like tables, chairs, desks, and shelving units.

In sheet metal work, corner joints are used to join panels and sheets at right angles. In the automotive industry, corner joints are valuable in the construction of vehicle bodies, frames, and components.

Pros and Cons Of Corner Joints in Welding

Pros of Corner Joints in Welding:

• Versatile joint design: Ideal for constructing frames, boxes, and enclosures, commonly used in metal fabrication, furniture, and construction.
• Pleasing aesthetics: Provides a clean, sharp edge that is visually appealing, especially after finishing.
• Vital for angular connections: Design provides good strength for right-angle connections.
• Simple Assembly: Easy to align and weld, especially in setups where a 90-degree connection is needed.

Cons of Corner Joints in Welding:

• Prone to distortion: Susceptible to warping and distortion due to heat when welding thin metals.
• Has weak spots: May require additional reinforcement in high-stress applications to prevent joint failure.
• Vulnerable to Cracks: If not welded properly, the joint can be prone to cracking at the corners, especially under stress.

Edge Joint Welding

Edge joints are similar to corner joints, but welders use them in applications where weldment is not subjected to any stress. Welders create an edge joint once workpieces leave the edges parallel or nearly parallel to one another. Then, they deposit the welds across the edges and in the middle of the joint, fusing both pieces.

Edge preparation in edge joints is primarily dependent on the application of the weldment. On thinner pieces, you don't need an edge preparation, so you are left with a square groove. However, as the thickness of the metal increases, you can bevel, cut, or grind the edges to achieve the proper penetration.

Once you prepare the edges, you can opt to weld only the main edge joint or all around the weldment. Welding all around provides an extra reinforcement, but it can be less aesthetic and requires some extra time spent in post-weld grinding.

Weld Types In Edge Joints

Depending on the application, base metal, and other factors, edge joints can utilize one of the following weld types:

• V-Groove Weld
• Flared V-Groove Weld
• J-Groove Weld
• U-Groove Weld
• Bevel Groove Weld
• Edge Flange Weld
• Corner Flange Weld
• Square Groove Weld

The ultimate choice will depend on the given situation or the welding engineer's calculations and weld specifications. Once there are no strict specifications, understanding the applications and limitations of edge joints is crucial in making the right choice.

Applications Of Edge Joints

Since edge joints are less strong than other welding joint types, their applications are limited. Welders typically use edge joints on lightweight structures, in sheet metal welding, and when welding metal plates.

Welders often use edge joints in the fabrication of sheet metal components that meet at the edges. Metal panels, hoods, ducts, and other sheet metal products are just some of the common uses.

Edge joints are precious in the construction of lightweight structures, such as in the aerospace and automotive industries. They can also join metal plates aligned side by side, later bent, shaped, or machined.

The pros and cons of edge joints in welding are almost similar to corner joints, with somewhat more limited strength.

Why Do You Need A Proper Joint Design?

As you can note, welding joint type can significantly impact the strength of your weldment or how the stress is distributed across the edges. As a result, using the right welding joint design can make or break your projects.

One type or another is more suitable for specific applications, so choosing the right weld joint can yield everlasting connections. Meanwhile, choosing the wrong one can cause a weld failure, and that's the last thing you will want in critical applications, but also with your home or hobby welding.
